Rod Breakdown Machine
KINGSTRONG Rod Breakdown Machine is designed for high-efficiency and high-precision drawing of copper and aluminum rods, delivering superior performance and operational stability. Based on advanced European technology and robust engineering, this machine is ideal for modern cable manufacturers who demand productivity and quality.
Series: SD450 / MSD450 / MMD450
Material: Copper and aluminium rod
Inlet: Copper 8.00 mm; aluminium 9.50-12.50 mm
Outlet: 1.00-4.50 mm, depending on material and series
Max. speed: 30-35 m/s; 1-2 wires, by configuration
Series: MD200 intermediate / MD150 fine drawing
Material: Pre-drawn copper and aluminium wire
MD200 outlet: 0.30-2.60 mm, depending on layout
MD150 outlet: 0.15-0.60 mm
Max. speed: 30-40 m/s; 1-2 wires, by configuration
Material: Pre-drawn copper and aluminium wire
MD200 outlet: 0.30-2.60 mm, depending on layout
MD150 outlet: 0.15-0.60 mm
Max. speed: 30-40 m/s; 1-2 wires, by configuration
--Maximum drawing speed:35 m/s
--Quick die change system without having to re-string the machine
--Drawing of up to 48 wires (up to 24 in one row) through 15 to 33 dies
--Quick die change system without having to re-string the machine
--Drawing of up to 48 wires (up to 24 in one row) through 15 to 33 dies
